BATTERY STRUCTURE
Battery model | Rated voltage | Rated capacity | Rated discharge current | Maximum discharge current | Appearance size(length,windth,heigth) | capacitance | Reference weight | Equalizing charging voltage | Floating charge voltage | 端子类型 | Terminal type |
12V17AH | 12 | 17 | 0.85 | 51 | 180*77*167 | 17 | 5KG | 14.4 | 13.8 | T3 | 20 hour rate |
12V24AH | 12 | 24 | 2.4 | 48 | 166*126*180 | 24 | 7.5 | 14.4 | 13.8 | T4 | 20 hour rate |
12V38AH | 12 | 38 | 3.8 | 76 | 197*166*174 | 38 | 10.5 | 14.4 | 13.8 | T14 | 20 hour rate |
12V50AH | 12 | 50 | 5 | 100 | 230*138*210 | 50 | 15 | 14.4 | 13.8 | T14 | 20 hour rate |
12V65AH | 12 | 65 | 6.5 | 130 | 230*138*210 | 65 | 18 | 14.4 | 13.8 | T14 | 20 hour rate |
12V80AH | 12 | 80 | 8 | 160 | 350*166*176 | 80 | 23 | 14.4 | 13.8 | T14(Underspin) | 20 hour rate |
12V100AH | 12 | 100 | 10 | 200 | 330*173*215 | 100 | 28.5 | 14.4 | 13.8 | T16(Underspin) | 20 hour rate |
12V120AH | 12 | 120 | 12 | 240 | 407*173*233 | 120 | 32.5 | 14.4 | 13.8 | T16(Underspin) | 20 hour rate |
12V150AH | 12 | 150 | 15 | 300 | 484*171*240 | 150 | 40.5 | 14.4 | 13.8 | T16(Underspin) | 20 hour rate |
12V180AH | 12 | 180 | 18 | 360 | 522*240*230 | 180 | 50 | 14.4 | 13.8 | T18(Underspin) | 20 hour rate |
12V200AH | 12 | 200 | 20 | 400 | 522*240*230 | 200 | 54.0 | 14.4 | 13.8 | T18(Underspin) | 20 hour rate |
